DPA10M-N — Digital pressure sensor Delta DPA series, -100 ~ 1,000 kPa (max. 1,100 kPa), 2 NPN switching outputs + analogue 1 ~ 5 V, connection 1/8" NPT male thread, M5 female, 12 ~ 24 VDC
Tootja: Delta Electronics · Kood: DPA10M-N
99,06 € km-ga / tk82,55 € km-ta
Tarne tellimisel — tarneaeg kinnitatakse hinnapakkumisega.
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Tootekirjeldus
Delta series DPA digital pressure sensor, -100 ~ 1,000 kPa (max. 1,100 kPa), 2 NPN switching outputs + analog 1 ~ 5 V, connection 1/8" NPT external thread, M5 internal thread, 12 ~ 24 VDC. Non-corrosive gases, relative pressure; accuracy ±3% of the range; two-line tri-color LCD display; response time 2 ~ 5,000 ms.
Tehnilised andmed
| Seeria | DPA |
|---|---|
| Suurus | 30 × 30 × 43,3 mm (paneeli ava 31 × 31 mm) |
| Väljund 1 | 2 × transistor NPN, 30 V / 100 mA |
| Väljund 2 | Analoog 1 ~ 5 V |
| Side | Puudub |
| Toide | 12 ~ 24 VDC ±10 % |
| Rõhuvahemik | -100 ~ 1 000 kPa |
| Häireväljundite arv | 2 (lülitusväljundit) |
| Tariifikood (KN/TARIC) | 9026 20 20 (9026202000) |
| Imporditollimaks kolmandatest riikidest | 0 % |
Dokumendid
