DPB10P-P — Digital pressure sensor Delta DPB series, -100 ~ 1,000 kPa (max. 1,500 kPa), 2 PNP switching outputs, 1/8" PT male thread connection
Tootja: Delta Electronics · Kood: DPB10P-P
61,26 € km-ga / tk51,05 € km-ta
Tarne tellimisel — tarneaeg kinnitatakse hinnapakkumisega.
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Tootekirjeldus
Delta series DPB digital pressure sensor, -100 ~ 1000 kPa (max. 1500 kPa), 2 PNP switching outputs, 1/8" PT threaded connection (external thread), M5 internal thread, 12 ~ 24 VDC. Non-corrosive gases, relative pressure; accuracy ±3% of the range; two-line LCD display; response time 2 ~ 5000 ms.
Tehnilised andmed
| Seeria | DPB |
|---|---|
| Suurus | 30 × 30 × 43,3 mm (paneeli ava 31 × 31 mm) |
| Väljund 1 | 2 × transistor PNP, 30 V / 100 mA |
| Side | Puudub |
| Toide | 12 ~ 24 VDC ±10 % |
| Rõhuvahemik | -100 ~ 1 000 kPa |
| Häireväljundite arv | 2 (lülitusväljundit) |
| Tariifikood (KN/TARIC) | 9026 20 20 (9026202000) |
| Imporditollimaks kolmandatest riikidest | 0 % |
Dokumendid
