DTM-BDC — Output expansion cassette Delta DTM, 4 channels: analog current 4 ~ 20 mA (≤ 500 Ω)
Fabricant: Delta Electronics · Référence: DTM-BDC
54,16 € TTC / pce45,13 € HT
Livraison sur demande — le délai est confirmé avec l’offre.
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description du produit
Delta DTM expansion module, 4 channels: analog current 4 ~ 20 mA (≤ 500 Ω). It is installed in the main DTM module or in the measurement module DTMN04 / DTMN08; powered by the module.
Données techniques
| Série | DTM |
|---|---|
| Taille | 25 × 48 × 77 mm |
| Sortie 1 | 4 × courant analogique 4 ~ 20 mA (≤ 500 Ω) |
| Alimentation | Par le module DTM |
| Code tarifaire (NC/TARIC) | 9032 90 00 (9032900090) |
| Droit de douane à l’importation de pays tiers | 2,8 % |
