JCVP 24 — Surface-mounting base JEI-V, size 104.27, entry Pg21, with two clips
Produttore: ILME · Codice: JCVP 24
41,76 € IVA inclusa / pz34,80 € IVA esclusa
Disponibile
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Descrizione del prodotto
JEI-V series. Protection class: IP65/IP66/IP69. Operating temperature: −40…+125 °C. Material: bracket: galvanized steel; seal: NBR.
Dati tecnici
| Serie | JEI®-V |
|---|---|
| Peso, g | 380 |
| Confezione, pz | 10 |
| Tipo | Base |
| Dimensione | 104.27 |
| Ingresso cavo | Pg21 |
| Numero di leve | 2 |
| Montaggio | da parete |
| Descrizione nel listino ILME | JEI HOUSING104.27 PG21 2L |
| EAN | 8015747137645 |
| Peso lordo, kg | 0,38 |
| Confezione: peso, kg | 7,6 |
| Codice doganale (NC/TARIC) | 8538 90 99 (8538909999) |
| Dazio all'importazione da paesi terzi | 1,7 % |
