ECM-E3M-CP0602SSE — Servo motor ECM-E3M, 0.2 kW, with brake
Manufacturer: Delta Electronics · Code: ECM-E3M-CP0602SSE
€548.30 incl. VAT / pc€456.92 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
ECM-E3M-CP0602SSE — servo motor ECM-E3M (medium inertia), 0.2 kW, 220 V · rated torque 0.64 N·m, maximum 2.24 N·m · rated speed 3000 min⁻¹, maximum 6000 min⁻¹ · flange 60 mm · 17-bit absolute magnetic encoder (16-bit multi-turn) · with electromagnetic brake 24 V DC · keyed shaft with oil seal, standard connector · for servo drives ASDA-E3.
Technical data
| Product type | Servo motor |
|---|---|
| Power, kW | 0,2 |
| Power supply | 230 V AC |
| Rated speed, min⁻¹ | 3000 |
| Max. speed, min⁻¹ | 6000 |
| Rated torque, N·m | 0,64 |
| Max. torque, N·m | 1,91 |
| Encoder | absolute magnetic |
| Encoder resolution, bit | 17 |
| Brake | Yes |
| Series | ASDA-E3 |
| Net weight, kg | 1,3 |
| Tariff code (CN/TARIC) | 8501 51 00 (8501510090) |
| Import duty from third countries | 2,7 % |
