PAOT 20 N — Flat anti-slip vacuum suction cup Ø20, side connection, NBR, Chelic PAO
Manufacturer: Chelic · Code: PAOT 20 N
Price on request
In stock
Description
Flat, anti-slip vacuum cup Ø20, side connection, NBR, Chelic PAO.
- A special relief on the inside of the suction cup absorbs large lateral forces during handling
- Code PAO T 20 N: T = side connection, Ø20, N = NBR.
- Overall length: 41 mm, mounting thread: M6×1.
- Tube, Ø mm: PU tube, ØD 4
Technical data
| Product type | Flat vacuum suction cup, anti-slip |
|---|---|
| Series | PAO |
| Suction cup diameter, mm | 20 |
| Connection | side (T), barb for PU tube; mounting thread M6×1 |
| Tube, Ø mm | 4 |
| Material | NBR, red, A60/S, −26–120 °C |
| Overall length, mm | 41 |
| Tariff code (CN/TARIC) | 4016 99 97 (4016999790) |
| Import duty from third countries | 2,5 % |
