6527 — Enclosure for up to 8 modules /installed 4xMCB 2P/16A / with sockets: 9×3PTL 16A, IP54
Manufacturer: Famatel · Code: 6527
€305.28 incl. VAT / pc€254.40 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
AcquaCOMBI industrial distribution board with sockets and circuit breakers. 2P+E poles, 16 A, 230 V, protection rating IP54, dimensions 500 × 230 × 155 mm, 8 modules, 9 sockets, color: light gray. Enclosure for 8 modules; sockets: 9 × Schuko 16 A 220 V; circuit breakers: 4 × 2P / 16 A, C-curve, 6 kA; identical on the bottom.
Technical data
| Section | Industrial socket boards |
|---|---|
| Group | EQUIPPED AND WIRED INDUSTRIAL BOARDS | with SOCKETS and MODULES - AcquaCOMBI IP54 |
| Product type | Industrial board with sockets and protective devices |
| Number of poles | 3 (2P+E) |
| Voltage, V | 230 |
| Current, A | 16 |
| Size | 500 × 230 × 155 mm |
| Degree of protection | IP54 |
| Colour | light grey |
| Number of modules | 8 |
| Number of sockets | 9 |
| Min. qty | 1 |
| Carton | 4 |
| Tariff code (CN/TARIC) | 8537 10 98 (8537109899) |
| Import duty from third countries | 2,1 % |
