ACS3-CAPWE000 — Power connector kit, motor side, straight, IP67
Manufacturer: Delta Electronics · Code: ACS3-CAPWE000
€97.32 incl. VAT / pc€81.10 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
ACS3-CAPWE000, Power connector kit, motor side, straight, IP67 · for 220–320 mm frame (F220~F320) motors, 5.5 kW and above · for ECM-B3M large motors · for ASDA-A3 and ASDA-B3 drives.
Technical data
| Product type | Accessory |
|---|---|
| Connector | Power connector |
| Accessory type | Accessory |
| Series | ASDA-A3 / B3 / E3 |
| Tariff code (CN/TARIC) | 8536 69 90 (8536699099) |
| Import duty from third countries | 2,3 % |
Documents
