AR1-F2B — Door safety switch AR1, plastic head, 2NC
Manufacturer: Akusense · Code: AR1-F2B
€37.50 incl. VAT / pc€31.25 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Safety door locks |
|---|---|
| Series | AR1 |
| Version | safety switch with separate actuator |
| Operating principle | Mechanical safety switch |
| Housing shape | Rectangular |
| Connection | Cable entry M20, terminals |
| Connection type | Cable entry M20 |
| Degree of protection | IP67 |
| Housing material | PA66, self-extinguishing |
| Operating temperature | −10 … +70 °C |
| Min. temperature, °C | -10 |
| Max. temperature, °C | 70 |
| Dimensions | 30 × 30,1 × 96 mm |
| Weight, g | 96,5 |
| Safety | PL e, SIL 3 |
| Contacts | 2NC |
| Locking | Mechanical locking |
| Head | Plastic |
| Tariff code (CN/TARIC) | 8536 50 80 (8536508000) |
| Import duty from third countries | 0 % |
