DPA10PR-P — Digital pressure sensor Delta DPA series, -100 ~ 1000 kPa (max. 1100 kPa)
Manufacturer: Delta Electronics · Code: DPA10PR-P
€129.65 incl. VAT / pc€108.04 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
Delta series DPA digital pressure sensor, -100 ~ 1000 kPa (max. 1100 kPa), 1 PNP switching output + RS-485 communication, 1/8" PT external thread, M5 internal thread, 12 ~ 24 VDC. Suitable for non-corrosive gases, relative pressure; accuracy ±3% of the range; two-line, tri-color LCD display; response time 2 ~ 5000 ms.
Technical data
| Series | DPA |
|---|---|
| Size | 30 × 30 × 43.3 mm (panel cut-out 31 × 31 mm) |
| Output 1 | 1 × PNP transistor, 30 V / 100 mA |
| Communication | RS-485 |
| Power supply | 12 ~ 24 VDC ±10 % |
| Pressure range | -100 ~ 1 000 kPa |
| Number of alarm outputs | 1 (switching output) |
| Tariff code (CN/TARIC) | 9026 20 20 (9026202000) |
| Import duty from third countries | 0 % |
