ECM-E3M-CM0602SSE — Servo motor ECM-E3M, 0.2 kW, with brake
Manufacturer: Delta Electronics · Code: ECM-E3M-CM0602SSE
€461.50 incl. VAT / pc€384.58 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
ECM-E3M-CM0602SSE, ECM-E3 AC servo motor 0.2 kW · 230 VAC · 3000 / 6000 rpm max · torque ~0.64 N·m (peak ~1.91 N·m) · 60 mm frame · 17-bit incremental magnetic encoder · with brake for ASDA-E3 drives.
Technical data
| Product type | Servo motor |
|---|---|
| Power, kW | 0,2 |
| Power supply | 230 V AC |
| Rated speed, min⁻¹ | 3000 |
| Max. speed, min⁻¹ | 6000 |
| Rated torque, N·m | 0,64 |
| Max. torque, N·m | 1,91 |
| Encoder | incremental magnetic |
| Encoder resolution, bit | 17 |
| Brake | Yes |
| Series | ASDA-E3 |
| Net weight, kg | 1,3 |
| Tariff code (CN/TARIC) | 8501 51 00 (8501510090) |
| Import duty from third countries | 2,7 % |
