ESB-BV30APE — Photoelectric sensor, diffuse with background suppression (BGS), 5 – 300 mm, PNP, light-on/dark-on, switchable, M8 connector, 4 pins
Manufacturer: Akusense · Code: ESB-BV30APE
€51.18 incl. VAT / pc€42.65 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Photoelectric sensors |
|---|---|
| Series | ESB |
| Version | rectangular, with background suppression |
| Operating principle | Photoelectric |
| Detection method | Diffuse with background suppression (BGS) |
| Housing shape | Rectangular |
| Measuring range, mm | 300 |
| Range | 5 – 300 mm |
| Output | PNP |
| Output function | Light-on/dark-on, selectable |
| Power supply | 10–30 V DC ±10 % |
| Load, mA | 100 |
| Frequency, Hz | 500 |
| Response time | ≤ 1 ms |
| Connection | M8 connector, 4-pin |
| Connection type | M8 connector |
| Degree of protection | IP67 |
| Housing material | PC + ABS, PMMA front |
| Light source | Infrared LED 940 nm |
| Adjustment | Potentiometer, 6 turns |
| Indication | Operation — green; output — red |
| Protections | reverse polarity, short circuit, overvoltage |
| Operating temperature | −25 … +55 °C |
| Min. temperature, °C | -25 |
| Max. temperature, °C | 55 |
| Dimensions | 31 × 20 × 11 mm |
| Weight, g | 10 |
| Repeatability | ≤ 5 % |
| Hysteresis | ≤ 5 % |
| Included | Screws, bracket, screwdriver |
| Tariff code (CN/TARIC) | 8536 50 19 (8536501900) |
| Import duty from third countries | 0 % |
