IKZ.02 — Signal lamp, 3 levels (red, yellow, green), buzzer 90 dB, 24 V DC, M22 — Teknokol
Manufacturer: Teknokol · Code: IKZ.02
Price on request
Delivered to order — lead time confirmed on request
Description
Signal lamp, 3 levels (red, yellow, green), 90 dB buzzer, 24 V DC, M22 — Teknokol.
- Light and sound signaling with three levels in three colors — alarm, warning, normal operation.
- Colors: red, green, yellow; LED with constant or flashing light, buzzer 90 dB; power supply 24 V DC.
- Mounted with an M22 x 1.5 nut — for M22 signal lamp housings on the TK045/TK060/TK120 arms.
- Dimensions Ø55 x 122 mm, connecting part 20 mm; each color and the buzzer are on a separate wire relative to the common 0 V.
Technical data
| Product type | Signal lamp |
|---|---|
| Version | 3 tiers, 3 colours |
| Colours | red, green, yellow |
| Opening | LED, steady or flashing — in one body |
| Buzzer | 90 dB |
| Power supply | 24 V DC |
| Connection | nut M22 × 1.5 |
| Dimensions, mm | Ø55 × 122 |
| Tariff code (CN/TARIC) | 8531 80 70 (8531807000) |
| Import duty from third countries | 0 % |
