LW30-63/4R1 — Cam switch-disconnector LW30, Switch-disconnector OFF–ON, 90°, 4P, Ith 63 A, Ue 440 V, AC-23A 22 kW, Rear panel mounting 1–4 mm, 4 holes (R), Grey plate
Code: LW30-63/4R1
€48.05 incl. VAT / pc€40.04 excl. VAT
In stock
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
OFF–ON disconnect switch, 90°. Main switch 3P+N on the panel; three-phase motors up to 22 kW (AC-23A, 440 V).
Technical data
| Series | LW30 |
|---|---|
| Function | Switch disconnector OFF–ON, 90° |
| Poles | 4P |
| Ith, A | 63 |
| Ue, V | 440 |
| AC-23A, kW | 22 |
| Mounting | Rear panel mounting 1–4 mm, 4 holes (R) |
| Plate / handle | Grey plate, black knob ø50 |
| Padlock | no |
| Plate, mm | 64×64 |
| Panel cut-out, mm | ø10 + 4×ø4.2 on 48×48 |
| Tariff code (CN/TARIC) | 8536 50 80 (8536508000) |
| Import duty from third countries | 0 % |
