PD-H42S — Fibre-optic cable, diffuse, head M4, 1800 mm
Manufacturer: Akusense · Code: PD-H42S
€232.58 incl. VAT / pc€193.82 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Fibre optic cables |
|---|---|
| Series | PD / PT-H |
| Version | high-temperature fibre optics |
| Operating principle | Fibre optic |
| Detection method | Diffuse |
| Housing shape | With short sleeve |
| Size | M4 |
| Housing material | Stainless steel |
| Operating temperature | up to +350 °C |
| Max. temperature, °C | 350 |
| Included | Nut, washer |
| Fibre optic type | Diffuse |
| Fibre optic head | M4 |
| Fibre optic length, mm | 1800 |
| Bending radius, mm | 25 |
| Fibre optic core | ø1,5 mm |
| Cuttable | No |
| Tariff code (CN/TARIC) | 9001 10 90 (9001109090) |
| Import duty from third countries | 2,9 % |
