PTE-DE15PR — Photoelectric sensor, diffuse, 1 – 150 mm, PNP, light-on/dark-on, switchable, cable 2 m, 4 cores
Manufacturer: Akusense · Code: PTE-DE15PR
€24.56 incl. VAT / pc€20.47 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Photoelectric sensors |
|---|---|
| Series | PTE |
| Version | rectangular 20 × 31 × 11 mm |
| Operating principle | Photoelectric |
| Detection method | Diffuse |
| Housing shape | Rectangular |
| Measuring range, mm | 150 |
| Range | 1 – 150 mm |
| Output | PNP |
| Output function | Light-on/dark-on, selectable |
| Power supply | 10–30 V DC ±10 % |
| Load, mA | 100 |
| Frequency, Hz | 300 |
| Response time | ≤ 1,6 ms |
| Connection | Cable 2 m, 4 cores |
| Connection type | Cable |
| Degree of protection | IP67 |
| Housing material | PBT |
| Light source | Red LED 660 nm |
| Adjustment | Potentiometer, 6 turns |
| Indication | Operation — green; output — red |
| Protections | reverse polarity, short circuit, overvoltage |
| Operating temperature | −25 … +55 °C |
| Min. temperature, °C | -25 |
| Max. temperature, °C | 55 |
| Dimensions | 20 × 31 × 11 mm |
| Weight, g | 50 |
| Repeatability | ≤ 5 % |
| Hysteresis | ≤ 20 % |
| Included | Nuts, bracket, screwdriver |
| Smallest detectable object | ø1 cm at 15 cm |
| Tariff code (CN/TARIC) | 8536 50 19 (8536501900) |
| Import duty from third countries | 0 % |
