PTN-T150NC — Photoelectric sensor, through-beam, up to 1500 mm, NPN, light-on, cable 2 m, 3 cores
Manufacturer: Akusense · Code: PTN-T150NC
€49.55 incl. VAT / pc€41.29 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Photoelectric sensors |
|---|---|
| Series | PTN |
| Version | rectangular, compact |
| Operating principle | Photoelectric |
| Detection method | Through-beam |
| Housing shape | Rectangular |
| Measuring range, mm | 1500 |
| Range | up to 1500 mm |
| Output | NPN |
| Output function | Light-on |
| Power supply | 12–24 V DC ±10 % |
| Load, mA | 100 |
| Frequency, Hz | 850 |
| Response time | ≤ 0,6 ms |
| Connection | Cable 2 m, 3 cores |
| Connection type | Cable |
| Degree of protection | IP67 |
| Housing material | PC |
| Light source | Red LED 637 nm |
| Indication | Operation — green; output — orange |
| Protections | reverse polarity, short circuit, overvoltage |
| Operating temperature | −25 … +55 °C |
| Min. temperature, °C | -25 |
| Max. temperature, °C | 55 |
| Dimensions | 28,15 × 14,7 × 10,5 mm |
| Weight, g | 48 |
| Included | Nuts, bracket, screwdriver |
| Smallest detectable object | 5 mm |
| Light spot | ø13 mm at 200 mm |
| Tariff code (CN/TARIC) | 8536 50 19 (8536501900) |
| Import duty from third countries | 0 % |
