TK060.500 — Support arm system module TK060: horizontal rotating module, S-shaped, hinge type between two profiles, rotation angle 315° (± 170°) — Teknokol
Manufacturer: Teknokol · Code: TK060.500
€314.64 incl. VAT / pc€262.20 excl. VAT
In stock
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
Intermediate hinge, rotating — Teknokol TK060.
- Intermediate hinge between two horizontal profiles - the two arms move semi-independently relative to each other.
- Weight 2.505 kg, dimensions 119 x 230 x 119 mm (W x H x D), rotation 310°.
- Designed for medium configurations
Technical data
| Product type | Hinge |
|---|---|
| System | TK060 |
| Version | rotating |
| Material | aluminium |
| Colour | RAL 7035 / RAL 7016 |
| Weight, kg | 2,505 |
| Dimensions, mm | 119 × 230 × 119 |
| Rotation | 310° |
| Degree of protection | IP65 |
| Static load capacity of the system | 1100 N (diagram 1) / 1000 N (diagram 2) up to 1000 mm; arm up to 3000 mm |
| Tariff code (CN/TARIC) | 8302 49 00 (8302490099) |
| Import duty from third countries | 2,7 % |
