13154 — Industrial surface-mounted plug 3P+N+T 16A 110V IP44 - Angled 90º

13154 — Industrial surface-mounted plug 3P+N+T 16A 110V IP44 - Angled 90º

Manufacturer: Famatel · Code: 13154

€7.30 incl. VAT / pc€6.08 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO wall plug, angled 90°. 3P+N+E, 16 A, 110 V~ 50/60 Hz, protected contact with a 4-hour timer, yellow color. Protection rating IP44; screw terminals; body made of polyamide PA6 and ABS; contacts made of nickel-plated brass; flexible conductor cross-section 1–2.5 mm²; dimensions 120 × 66 × 90 mm (H × W × D).

Technical data

SectionIndustrial plugs and sockets
GroupWALL-MOUNTED PLUGS IP44| 16A / 32A – Angled 90º SpeedPRO
Product typeWall-mounted plug
Number of poles5 (3P+N+E)
Voltage, V110
Current, A16
Size120 × 66 × 90 mm
Degree of protectionIP44
Colouryellow
Min. qty2
Carton24
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
