13396 — Industrial plug, surface-mounted 3P+T 32A 400V IP44 - Angled 90º ECO
Manufacturer: Famatel · Code: 13396
€6.54 incl. VAT / pc€5.45 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Description
SpeedPRO, ECO wall plug. 3P+E, 32 A, 400 V~ 50/60 Hz, 6-hour protective contact, red color. Protection rating IP44; screw terminals; body made of polyamide PA6 and ABS; contacts made of nickel-plated brass; flexible conductor cross-section 1–2.5 mm²; weight 221 g. Impact resistance IK08.
Technical data
| Section | Industrial plugs and sockets |
|---|---|
| Group | WALL-MOUNTED PLUGS IP44 | 16A / 32A – Angled 90º ECO-SpeedPRO |
| Product type | Wall-mounted plug |
| Number of poles | 4 (3P+E) |
| Voltage, V | 400 |
| Current, A | 32 |
| Degree of protection | IP44 |
| Colour | red |
| Min. qty | 3 |
| Carton | 36 |
| Tariff code (CN/TARIC) | 8536 69 90 (8536699099) |
| Import duty from third countries | 2,3 % |
