13533 — Industrial panel-mounted plug - Straight 3P 4h 32A 100-130V IP44/54

13533 — Industrial panel-mounted plug - Straight 3P 4h 32A 100-130V IP44/54

Manufacturer: Famatel · Code: 13533

€6.13 incl. VAT / pc€5.11 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO flush-mount plug, straight. 2P+E, 32 A, 110 V~ 50/60 Hz, protected contact with a 4-hour timer, yellow color. Protection class IP44/IP54; screw terminals; body made of polyamide PA6 and ABS; nickel-plated brass contacts; nut-free mounting; flexible conductor cross-section 2.5–6 mm²; flange 75 × 75 mm.

Technical data

SectionIndustrial plugs and sockets
GroupPANEL-MOUNTED PLUGS IP44/54 | Straight 16A / 32A –SpeedPRO
Product typePanel-mounted plug
Number of poles3 (2P+E)
Voltage, V110
Current, A32
Size75 × 75 mm (flange)
Degree of protectionIP44/IP54
Colouryellow
Min. qty5
Carton60
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
