14310 — Industrial portable plug 2P+T 32A 400V IP66/67

14310 — Industrial portable plug 2P+T 32A 400V IP66/67

Manufacturer: Famatel · Code: 14310

€4.99 incl. VAT / pc€4.16 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO mobile plug. 2P+E, 32 A, 400 V~ 50/60 Hz, 9-hour protective contact, red color. Protection rating IP66/IP67; screw terminals; polyamide PA6 housing; nickel-plated brass contacts; double mounting system - quick threaded connection and integrated anti-loosening clip.

Technical data

SectionIndustrial plugs and sockets
GroupPORTABLE PLUGS IP66/67 | 16A / 32A – SpeedPRO
Product typePortable plug
Number of poles3 (2P+E)
Voltage, V400
Current, A32
Sizeø92 × 172 mm
Degree of protectionIP66/IP67
Colourred
Min. qty4
Carton48
Net weight, kg0,232
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
