14505 — Industrial plug with straight housing, surface-mounted 2P+T 63A 110V IP67

14505 — Industrial plug with straight housing, surface-mounted 2P+T 63A 110V IP67

Manufacturer: Famatel · Code: 14505

€27.52 incl. VAT / pc€22.93 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO wall plug, angled 10°. 2P+E, 63 A, 110 V~ 50/60 Hz, protected outlet with a 4-hour timer, yellow color. Protection class IP67; screw terminals with internal hexagon; body made of polyamide PA6 and ABS; contacts made of nickel-plated brass, with pilot contact; cable entry from the top, 2 × from the bottom and from the back.

Technical data

SectionIndustrial plugs and sockets
GroupWALL-MOUNTED SOCKETS AND PLUGS IP67 | 63A – SpeedPRO
Product typeWall-mounted plug
Number of poles3 (2P+E)
Voltage, V110
Current, A63
Size220 × 118 × 190 mm
Degree of protectionIP67
Colouryellow
Min. qty1
Carton3
Net weight, kg0,84
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
