23373 — Industrial panel-mounted socket - Straight 3P+N+T 32A 400V IP44/54

23373 — Industrial panel-mounted socket - Straight 3P+N+T 32A 400V IP44/54

Manufacturer: Famatel · Code: 23373

€7.72 incl. VAT / pc€6.43 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO flush-mounted socket, straight. 3P+N+E, 32 A, 400 V~ 50/60 Hz, 6-hour timer, red color. IP44/IP54 protection rating; screw terminals; polyamide PA6 and ABS housing; brass contacts; nut-free mounting; flexible conductor cross-section 2.5–6 mm²; flange 75 × 75 mm.

Technical data

SectionIndustrial plugs and sockets
GroupPANEL-MOUNTED SOCKETS IP44/54 | Straight 16A / 32A-SpeedPRO
Product typePanel-mounted socket
Number of poles5 (3P+N+E)
Voltage, V400
Current, A32
Size75 × 75 mm (flange)
Degree of protectionIP44/IP54
Colourred
Min. qty5
Carton60
Net weight, kg0,245
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
