23471 — Industrial panel-mounted socket - Straight 3P+N+T 16A 500V IP44/54

23471 — Industrial panel-mounted socket - Straight 3P+N+T 16A 500V IP44/54

Manufacturer: Famatel · Code: 23471

€6.16 incl. VAT / pc€5.13 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO flush-mount contact, straight. 3P+N+E, 16 A, 500 V~ 50/60 Hz, protected contact for 7 h, black color. Protection rating IP44/IP54; screw terminals; body made of polyamide PA6 and ABS; contacts made of brass; fastening without nuts; flexible conductor cross-section 1–2.5 mm²; flange 75 × 75 mm.

Technical data

SectionIndustrial plugs and sockets
GroupPANEL-MOUNTED SOCKETS IP44/54 | Straight 16A / 32A-SpeedPRO
Product typePanel-mounted socket
Number of poles5 (3P+N+E)
Voltage, V500
Current, A16
Size75 × 75 mm (flange)
Degree of protectionIP44/IP54
Colourblack
Min. qty8
Carton96
Net weight, kg0,175
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
