24275 — Industrial panel-mounted socket - Straight 3P+T 32A 230V IP66/67

24275 — Industrial panel-mounted socket - Straight 3P+T 32A 230V IP66/67

Manufacturer: Famatel · Code: 24275

€7.52 incl. VAT / pc€6.27 excl. VAT

Delivered to order — lead time confirmed on request

Open in the e-shop — inquiry and order

Prices are indicative; send an inquiry for a firm quotation.

Description

SpeedPRO flush-mount socket, straight. 3P+E, 32 A, 230 V~ 50/60 Hz, protected contact with a 9-hour timer, blue color. Protection rating IP66/IP67; screw terminals; body made of polyamide PA6 and ABS; contacts made of brass; mounting without nuts; flexible conductor cross-section 2.5–6 mm²; flange 75 × 75 mm.

Technical data

SectionIndustrial plugs and sockets
GroupPANEL-MOUNTED SOCKETS IP66/67 | Straight 16A / 32A-SpeedPRO
Product typePanel-mounted socket
Number of poles4 (3P+E)
Voltage, V230
Current, A32
Size75 × 75 mm (flange)
Degree of protectionIP66/IP67
Colourblue
Min. qty5
Carton60
Tariff code (CN/TARIC)8536 69 90 (8536699099)
Import duty from third countries2,3 %
