AR3-D2GFH — Safety lock AR3, solenoid locking 24 V DC, mechanical release, metal head, 1NC/1NO + 1NC/1NO
Manufacturer: Akusense · Code: AR3-D2GFH
€275.46 incl. VAT / pc€229.55 excl. VAT
Delivered to order — lead time confirmed on request
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Safety door locks |
|---|---|
| Series | AR3 |
| Version | solenoid lock, narrow |
| Operating principle | Solenoid interlock |
| Housing shape | Rectangular |
| Power supply | Solenoid 24 V DC |
| Connection | Cable entry M20, terminals |
| Connection type | Cable entry M20 |
| Degree of protection | IP67 |
| Housing material | PA66, self-extinguishing |
| Indication | Green LED |
| Operating temperature | −10 … +55 °C |
| Min. temperature, °C | -10 |
| Max. temperature, °C | 55 |
| Dimensions | 38 × 38,6 × 165 mm |
| Weight, g | 253,4 |
| Safety | PL e, SIL 3 |
| Contacts | 1NC/1NO + 1NC/1NO |
| Locking | Locking by 24 V DC solenoid, mechanical release |
| Head | Metal |
| Key entry | Rear |
| Key | Standard, plastic |
| Tariff code (CN/TARIC) | 8536 50 80 (8536508000) |
| Import duty from third countries | 0 % |
