MLD25-30PV — Laser distance sensor, triangulation, 25 – 35 mm, PNP + analog (0–5 V or 4–20 mA)
Manufacturer: Akusense · Code: MLD25-30PV
€248.80 incl. VAT / pc€207.33 excl. VAT
In stock
Open in the e-shop — inquiry and order
Prices are indicative; send an inquiry for a firm quotation.
Technical data
| Category | Laser distance sensors |
|---|---|
| Series | MLD25 |
| Version | laser triangulation |
| Operating principle | Laser triangulation |
| Detection method | Diffuse |
| Housing shape | Rectangular |
| Measuring range, mm | 35 |
| Range | 25 – 35 mm |
| Output | PNP + analogue (0–5 V or 4–20 mA) |
| Output function | Light-on/dark-on, selectable |
| Power supply | 12–24 V DC ±10 % |
| Load, mA | 100 |
| Response time | 1.5 ms/5 ms/10 ms, selectable |
| Connection | Cable 2 m, 6 cores |
| Connection type | Cable |
| Degree of protection | IP67 |
| Housing material | Die-cast aluminium |
| Light source | Red laser 655 nm, 1 mW, class 2 |
| Protections | reverse polarity, short circuit, overload, overvoltage |
| Operating temperature | −10 … +45 °C |
| Min. temperature, °C | -10 |
| Max. temperature, °C | 45 |
| Dimensions | 20 × 28 × 45 mm |
| Weight, g | 90 |
| Repeatability | 10 µm |
| Included | Cable |
| Light spot | ø40 µm |
| Measuring range | 25 – 35 mm |
| Linearity | ±0.1 % of full scale |
| Interface | RS-485 |
| Tariff code (CN/TARIC) | 9031 49 90 (9031499000) |
| Import duty from third countries | 0 % |
